Open Source FPV hardware for all.
opendrone.be · Discord · Roadmap
| Repo | What it is | Status |
|---|---|---|
| OpenESC-30x30 | 4in1 AM32 Electronic Speed Controller, 30x30, 8S | Beta |
| OpenESC-20x20 | 4in1 AM32 Electronic Speed Controller, 20x20, 6S | Beta |
| OpenFC-Lite | Betaflight Flight Controller on RP2350, 30x30 | Beta |
| OpenFC-Lite-Mini | Betaflight Flight Controller on RP2350, 20x20 | Beta |
| OpenRX | ExpressLRS Receivers: Lite and Lite-UFL on SX1281, Mono and Gemini on LR1121 | Alpha |
| OpenAIO | AIO: flight controller, 4in1 ESC and ELRS receiver on one board | Planned |
| OpenAIO-Whoop | Whoop-size AIO with Bluejay ESCs | Planned |
| OpenVTX | Video transmitter | Planned |
| OpenRemoteID | Remote ID module | Planned |
| Charger | LiPo charger | Planned |
| KiCad-Library | Symbols, footprints and 3D models sharing common parts |
Beta means buyable, first production batch, design can still change between batches. Alpha means in test with community testers and firmware maintainers, not buyable yet. Planned means the spec discussion is open on Discord and there is no design. The live state is on the roadmap.
If it ain't broke, don't fix it. The boards run Betaflight, AM32 and ExpressLRS
Hardware is CERN-OHL-S-2.0: fork it, sell it, but publish your changes.
OSHWA certified open source hardware: OpenFC-Lite, OpenFC-Lite-Mini, OpenESC-20x20, OpenESC-30x30, and OpenRX Lite, Lite-UFL, Mono and Gemini.
Issues and pull requests are welcome on any repo. KiCad files cannot be merged, so say what you intend to change before you do on discord.
